Solid State Marine Battery 48V 120 Ah

Solid State Marine Battery 48V 120Ah Description:

Specifications

Cell Type: Solid State

Cycle Life: 3000 cycles at 100% DOD

Nominal Voltage: 50.4 V

Rated Capacity: 120 Ah

Energy: 10,584 Wh

Max. Expansion (Parallel & Series): 4P2S

Internal Resistance: ≤40mΩ

Certifications: UL 1642, UN38.3 ABYC Official Cert.

BMS

BMS: 120 Ah

Max. Continuous Output Power: 10,584 Wh

Max. Continuous Charge Current: 100 A

Max. Continuous Discharge Current: 250 A

CCA (Equivalent): 1500

CHARGE

Charge Method: CC/CV

Charge Voltage: 58.8V±1V

Recommend Charge Current: Up to 60A (0.5C)

TEMPERATURE

Charge Temperature: -20℃ to 70℃ / -4℉ to 155℉

Discharge Temperature: -20℃ to 70℃ / -4℉ to 155℉

Storage Temperature: -20℃ to 50℃ / -4℉ to 122℉

Low-Temperature Protection: Yes (-4℉/-20℃)

LT Charging Protection Auto Recovery: Yes (-4℉/-20℃)

OTHER

Terminals: M8 bolts

Weight Approx.: 100 lbs

Size: L20.47*W10.55*H10.88 inch (group 8D size)

Housing Material: ABS (Flame Retardant Plastic)

Protection Class: IP67

6050Wh

Weights only 64 lbs

Max. Continuous Discharge - 250A

Non-combustible meaning its safer than Lithium, AGM and LFP batteries

Works without the use of a heater at -20°C

Extreme conditions proof up to 69°C

Bluetooth built-in

Built-in Battery Management System

IP67 Rated

Size of box - 52cm x 27cm x 27.6cm (8D)
